TECHNICAL DATA

Size	XS	S	M
Cells	35	35	35
Area flat (m²)	16.3	18.7	21.1
Area projected (m²)	14.00	16.00	18.10
Wingspan flat (m)	8.4	9.0	9.6
Wingspan projected (m)	6.75	7.24	7.69
Aspect ratio flat	4.33	4.33	4.33
Aspect ratio projected	3.27	3.27	3.27
min. profile depth (cm)	95	102	109
max. profile depth (cm)	237	254	269
Glider weight (kg)*	2.4*	2.6*	2.8*
Certified weight range (kg) EN/LTF B	/	50 – 85	65 – 105
Certified weight range (kg) EN/LTF C	50 – 95	86 – 105	106 – 120

*Glider weight with light Dyneema-Riser. Weight with Regular-Riser +200g.

WEIGHT RANGE

The application range of the TONIC2 is extremely versatile, depending on the size you choose. The reactions vary depending on the glider size and the corresponding wing loading. With low wing loading the TONIC2 is suitable for thermal flying. With high wing loading it becomes a real mini wing, a strong-wind rocket on cliffs and dunes.

The graphic below is meant as a guide to help you choose the right size. If in doubt, seek expert advice!

SKYWALK TONIC2 Lightweight Paraglider COLOURS

Standard Colours: Mustard and Lind

OPTIONS

• Risers: Standard (recommended); Dyneema (-200g)

THE FUN MACHINE.

ENERGETIC. DIRECT.

The TONIC2 is not only a perfect strong-wind glider but also an ideal practice glider for ground-handling, wingover and looping training and a perfect companion for hike&fly tours. It has enough performance to glide out of every valley or even stay up on thermal days.

A carefully selected mix of materials ensures the necessary robustness in dunes as well as low weight for hike&fly. A special feature is the trimmer riser with which the speed window can be significantly increased. One thing is common to all sizes: The TONIC2 is extremely easy to handle, extremely fun in the air and extremely tough!

HOW DOES THE SKYWALK TONIC2 Lightweight Paraglider?

The TONIC2 can be laid out in the smallest area due to its small span and short lines. Launch preparations are incomparably easy. A tug on the lines and the canopy rises compactly and evenly. Because the TONIC2 develops lift fast, the pilot takes off quickly – this was an important point in the specifications when developing the new mini-wing.

The TONIC2 immediately converts control inputs and weight shifting into high banks and steep curves. The reactions are moderate and manageable, but if you have no experience with mini-wings, you should approach this feature slowly.

The reactions vary depending on the size and the corresponding surface loading. With a low load, the TONIC2 is suitable for thermal flying, but if it is heavily loaded it becomes a strong-wind rocket on cliffs and dunes.

In turbulence, the TONIC2 remains stable but requires an active flying style due to its agility – especially at high wing loading. The brake line pressure increases sharply right up to the stall, and you can adjust your speed precisely for landing with the brakes.

SKYWALK TONIC2 Lightweight Paraglider FEATURES

JET FLAPS

Skywalk jet flaps extend the green arc as you approach the stall point, which substantially increases safety and also improves climb performance.

RIGID FOIL

The Rigid Foil nylon wires on the leading edge help maintain its shape and ensure constant ram air pressure. Advantages: better takeoff behaviour, more performance and lower canopy weight.

3D-SHAPING

A precise calculation of the leading edge geometry and the installation of an additional strip of fabric reduce wrinkling in this sensitive part of the glider. Advantages: exact wing shape, more performance.

LOOPS & HOOKS

Skywalk loops and straps on the topsail make it possible to layout the canopy in the most difficult alpine terrain.

MINI RIBS

Doubling the number of cells at the trailing edge increases its shape stability substantially. Advantage: fewer vortices improve the aerodynamics and with it the performance.

SHARK NOSE

Together with corresponding wing design, the shark nose technology improves pressure distribution in the canopy substantially. Advantages: much more solid flying feeling and substantial performance gain, especially when gliding on bar.

AUTOMATIC SAND RELEASE SYSTEM

Porous openings of the profile ribs at the trailing edge ensure that sand and dirt in the glider are automatically guided to the wingtip where they can trickle out. This helps preserve the material and “relieves” the trailing edge.

SKYWALK TONIC2 Lightweight Paraglider MATERIALS

Upper sail	Porcher Skytex 38g / Dominico Dokdo 32g
Lower sail	Porcher Skytex 27g
Ribs	Skytex 27 hard
Bands	Skytex 27 hard
Main lines	Liros PPSLS 180
Middle lines	Liros PPSLS 125/65
Toplines	Liros DC60
Brake lines	Liros DFLP 200/32, Liros PPSLS 65
Regular-Risers	Güth & Wolf 12mm Gurtband
Dyneema-Risers	Liros 6mm Dyneema



SKYWALK TONIC2 Lightweight Paraglider  package
